GAX-MD23 2 In 2 Out USB High-Fidelity Audio interface Studio Quality for Recording Music Songwriting Streaming and Podcasting
Product Description
studio products in Harar, Ethiopia
Specification
|
MIC INPUT 1-2 (balanced)
Frequency response: -1/-1dB, 20Hz-20kHz Dynamic Range: 82 dB, A weighting THD+N: 0.03%, 1kHz Maximum input level: +6dBulnput resistance 4kΩ Gain range: +3dB- +60dB HI-Z INPUT 2(Unbalanced) Maximum input level: +3.0dBV Input resistance: 1 MΩ Gain range: 0dB-+40dB LINE INPUT ½(Unbalanced) Maximum input level: +10dBu Input resistance: 18.5kΩ Gain range: -10dB-+40dB MAIN OUTPUT (lmpedance balance) Frequency response: -1/-1dB, 20Hz-20kHz Dynamic Range: 82 dB, A weighting THD+N: 0.03%, 1kHz Maximum output level: +6dBu Output resistance: 100Ω PHONES Maximum input level: 15mW +15mW40Ω USB Technical specifications: full speed USB 2.0, 24bit 44.1kHz/48kHz/88.2kHz/96kHz/176.4kHz/192kHz XLR INPUT Polarity:1 Grounding 2: Hot wire(+) 3: Cold wire (one) Power requirements: >5W |
